Chip Hi3516DV300
Computing power 1 TOPS
Memory DDR3 1.0 GB
Flash SPI NAND FLASH 512.0 MB
Sensor maximum image size 5MP 2560(H)*1920(V)
Sensor photosensitive surface size 1/2.7"
Minimum illumination color: 0.005Lux (F1.6, AGC ON), black and white: 0.0025Lux (F1.6, AGC ON), 0Lux (infrared on)
Lens focal length 2.8-12mm
Lens viewing angle: horizontal: 30.6° (T end) ~ 94° (W end); vertical: 24° (T end) ~ 70° (W end)
Infrared light fill distance 30m
Video encoding format MJPEG/H.264/H.265
Audio encoding format G.711a/G.711u/G.726/OPUS
Heat map support
Behavior analysis: fast movement detection, line crossing detection, intrusion detection, area entry/exit detection, loitering detection
Crowd situation analysis: queue length statistics, regional people statistics, people flow statistics
Face face detection, face attribute detection, face recognition
Human body detection
RS485 interface supported
Switching interface support
