Support 1 TOPS computing power;
Supports automatic tracking, behavior analysis, crowd situation analysis, target, human body, machine and non-human, vehicle, vehicle event detection, and traffic data statistics;
Supports backlight adaptation and fog penetration adaptation;
Using 1/2.7" CMOS;
Software definition supports online loading and upgrade of algorithms;
120dB super wide dynamic range, restoring true details in high-contrast scenes;
Vehicle Mainland China plate recognition, body color detection, car model detection, car model detection
Vehicle event detection: non-occupancy detection, non-occupancy detection, illegal parking detection, retrograde/reversing detection
Traffic data statistics: traffic flow statistics, non-motor vehicle flow statistics, pedestrian statistics
Behavior analysis: fast movement detection, line crossing detection, intrusion detection, area entry/exit detection, loitering detection
Crowd situation analysis: queue length statistics, regional people statistics, people flow statistics
Target target detection, target attribute detection
Human body detection
Machine is not a human. Machine is not a human. Detection of cyclist attributes.
Computing power 1 TOPS
Sensor photosensitive surface size 1/2.7" CMOS
Minimum illumination color: 0.005Lux (F1.2, AGC ON, 1/30 shutter), black and white: 0.0005Lux (F1.2, AGC ON, 1/30 shutter), 0Lux (infrared on)
Lens focal length 5.3-175mm
Lens viewing angle Horizontal 54°(W)~2.4°(T), Vertical 40.2°(W)~1.7°(T) Viewing angle tolerance ≤5%
Infrared light fill distance 150m
White light fill light distance 30m
Video encoding format MJPEG/H.264/H.265
Video frame rate 30/25fps can be set, the default value is 25fps
Audio encoding format G.711a/G.711u/G.726/OPUS/AAC
Pan-tilt rotation angle: horizontal 0°～360°, vertical -15°～90°
PTZ horizontal speed keying speed: 0.1°~100°/S Preset position speed: 100°/S; Note: The PTZ needs to limit the speed when it is low temperature. Enter the low temperature speed limit temperature: -20 degrees and exit the low temperature speed limit temperature: -10 Horizontal speed limit: 30 degrees per second Vertical speed limit: 20 degrees per second
PTZ vertical speed keying speed: 0.1~80°/s Preset position speed: 80°/s; Note: The PTZ needs to limit the speed when it is low temperature. Enter the low temperature speed limit temperature: -20 degrees. Exit the low temperature speed limit temperature: -10 degrees. Horizontal speed limit: 30 degrees per second Vertical speed limit: 20 degrees per second
Ethernet interface supported
Number of Ethernet interfaces: 1
Ethernet interface bandwidth 1 RJ45 10M/100M Ethernet port
Power supply type AC24V,POE(IEEE 802.3At)
Power consumption: Maximum power consumption: 22.3W, typical power consumption: 8.9W
Working temperature -30℃~60℃ (the fill light is not turned on) -30℃~40℃ (the fill light is turned on)
Working humidity 5%~95% (no condensation)
Protection grade IP66
Sensor photosensitive surface size 1/2.7" CMOS
Minimum illumination color: 0.005Lux (F1.2, AGC ON, 1/30 shutter), black and white: 0.0005Lux (F1.2, AGC ON, 1/30 shutter), 0Lux (infrared on)
Shutter shutter: 1/25-1/100000; Behavior analysis default value: shutter limit: 1/25, shutter value: 1/25; Single card default value: shutter limit: 1/25, shutter value: 1/25; Single microcard default value: shutter limit: 1/250, shutter value: 1/25;
Day and night mode supported; automatic (ICR)/color/black and white/timing Default automatic Sensitivity high, medium, low Default high Image trigger/internal trigger
Gain control: During manual exposure, a total of 101 steps from 0 to 100 can be set in steps of 1. Default is 0.
White balance automatic/manual/one-key trigger
Digital noise reduction 2D/3D noise reduction
Wide dynamic range 120dB
Strong light suppression support
Video anti-shake function supported; sensitivity not supported;
Optical fog transmission not supported
Algorithm fog penetration support
Exposure compensation support
Exposure mode support
Signal-to-noise ratio >45dB
Electric focus support
Day and night focus compensation support
Backlight adaptive support
Fog adaptive support
Mirror mode supports image mirroring (horizontal mirroring, vertical mirroring, horizontal and vertical mirroring)
Digital zoom support
Privacy masking support
Lens focal length 5.3-175mm
Maximum aperture F1.6-F4.4
Lens aperture type Precision aperture (DC-Iris+Hall)
Lens viewing angle Horizontal 54°(W)~2.4°(T), Vertical 40.2°(W)~1.7°(T) Viewing angle tolerance ≤5%
Built-in infrared light support
Infrared light fill distance 150m
Built-in white light support
White light fill light distance 30m
Video encoding format MJPEG/H.264/H.265
Number of video encoding channels: three streams
Main stream resolution 2880×1620(5MP), 2560×1440(4MP), 2304×1296(3MP), 1920×1080(1080P), 1280×720(720P)
Substream resolution Substream one: 720×576 (PAL), 720×480 (NTSC), 352×288 (PAL), 352×240 (NTSC); Substream two: 352×288 (PAL), 352×240(NTSC)
Video frame rate 30/25fps can be set, the default value is 25fps
Video bit rate only for H.264 and H.265 1080P~4K 512Kbps ~ 16Mbps 720P 384Kbps ~ 8Mbps D1 256K ~ 4Mbps CIF 32K ~ 1Mbps
Smart Coding Extra265/264
ROI (Region of Interest Coding) Each channel supports 4 groups. The quality of ROI relative to non-ROI is adjustable from 0 to 10 in steps of 1.
Audio encoding format G.711a/G.711u/G.726/OPUS/AAC
Audio sampling rate G.711a/G.711u/G.726: 8K OPUS: 8K/12K/16K/24K/48K AAC: 8K/16K/22.05K/24K/32K/44.1K/48K
Audio code rate G.711a/G.711u: 64kbps; G.726: 16, 24, 32, 40kbps can be set; OPUS: 16/24/32/40/64/96/128/160/192/224/256 /288Kbps can set AAC: 8K sampling rate, can be set to 16/22/24/32/48kbps 16K sampling rate, can be set to 24/32/48/64/96kbps 22.05/24K/32K sampling rate, can be set to 32/48/ 64/96/128kbps 44.1K/48K sampling rate, can be set to 48/64/96/128/256kbps
Pan-tilt rotation angle: horizontal 0°～360°, vertical -15°～90°
PTZ horizontal speed keying speed: 0.1°~100°/S Preset position speed: 100°/S; Note: The PTZ needs to limit the speed when it is low temperature. Enter the low temperature speed limit temperature: -20 degrees and exit the low temperature speed limit temperature: -10 Horizontal speed limit: 30 degrees per second Vertical speed limit: 20 degrees per second
PTZ vertical speed keying speed: 0.1~80°/s Preset position speed: 80°/s; Note: The PTZ needs to limit the speed when it is low temperature. Enter the low temperature speed limit temperature: -20 degrees. Exit the low temperature speed limit temperature: -10 degrees. Horizontal speed limit: 30 degrees per second Vertical speed limit: 20 degrees per second
Watch mode support
Cruise track support
Preset positions support 512 (including 1 guard position)
Guard position support
Vehicle Mainland China plate recognition, body color detection, car model detection, car model detection
Vehicle event detection: non-occupancy detection, non-occupancy detection, illegal parking detection, retrograde/reversing detection
Traffic data statistics: traffic flow statistics, non-motor vehicle flow statistics, pedestrian statistics
Behavior analysis: fast movement detection, line crossing detection, intrusion detection, area entry/exit detection, loitering detection
Crowd situation analysis: queue length statistics, regional people statistics, people flow statistics
Target target detection, target attribute detection
Human body detection
Machine is not a human. Machine is not a human. Detection of cyclist attributes.
Automatic tracking support
The SD interface supports the maximum capacity. Provides a MicroSD card slot, supports MicroSDHC/MicroSDXC, and supports a maximum capacity of 256GB memory card.
Audio input interface supported (2 channels built-in MIC)
Audio output interface supported (1-way speaker)
Ethernet interface supported
Number of Ethernet interfaces: 1
Ethernet interface bandwidth 1 RJ45 10M/100M Ethernet port
Access protocol GB/T 28181 (2011, 2016 protocol specifications), SDK (private protocol), Rest API (private protocol), GA/T 1400
Protocols supported by IPV4: TCP, UDP, IPv4, DHCP, DNS, ICMP, IGMP, HTTPS, FTP, SFTP, RTP, RTSP, RTCP, SIP, ARP, SSL, NTP, SNMP (V1/V2/V3), 802.1x, QoS, SMTP, PPPOE Note: 1 Northbound protocol should be adapted to PPPOE dial-up scenarios
Protocols supported by IPV6 HTTPS, RTP, RTCP, RTSP, Onvif, IPv6, ICMPv6, DHCPv6
Business constraints Web pages supported by IPV6: live (static IPV6), recording (static IPV6), IPv6 IP (including static IP, routing announcement) configuration, DHCPv6 configuration Onvif: live (static IPV6), recording (static IPV6), IPv6 IP (Including static IP, route announcement) configuration, DHCPv6 configuration, Probe service not supported Note: 1. Does not support IPV6 multicast 2. Does not support DNS 3. Does not support IP conflict detection
User permissions are divided into three levels: administrator, senior operator, and ordinary operator
Security mode Username and password authentication, support 802.1.x, HTTPS digital certificate
Video digital watermark support
Image digital watermark support
GB35114 support
Secure boot support
Security/encryption intrusion detection support
Power supply type AC24V,POE(IEEE 802.3At)
Power consumption: Maximum power consumption: 22.3W, typical power consumption: 8.9W
Working temperature -30℃~60℃ (the fill light is not turned on) -30℃~40℃ (the fill light is turned on)
Working humidity 5%~95% (no condensation)
Lightning protection and surge protection 6kV
Protection grade IP66
Overall machine weight 2.6kg
Packing weight 4.5kg
Overall machine size 202.6mm*202.6mm*260mm
Packaging size 285mm*285mm*375mm
Accessories
Ball machine column bracket
ACC3631
(21154636)
Ball machine corner mounting bracket
ACC3651
(21154638)
Ball machine wall mount bracket
ACC3611
(51661JVP)
Ball machine lifting bracket
ACC3621
(51661MCK)
